Front Panel Display for a Rep Rap 3D printer

by on Jul.20, 2011, under Arduino, Arduino Projects, Electronics, Projects, Prusa

Ben sent me this writeup of his progress on his Rep Rap Prusa printer. Here’s his progress using one of the teensyduinos that PJRC: Electronic Projects with Components sent us.

I am currently building a rep rap Prusa 3D printer and one feature I want to add is a Graphic Display to display the nozzle temperature and the heated bed temperature. Once I had the Teensy in my hands, I rummaged through my parts bin and found a 128×64 graphic LCD.

As an Arduino newbie, I was blown away how easy the Arduino environment is to get up and running. Within minutes, I was able to get the IDE installed and the Libraries installed for the Teensy.

Using the GLCD example on the Teensy’s website, I populated my breadboard. The Crystal Fontz LCD (CFAG12864B-YYH-N) I used in the project has the NT7107C driver, not the KS0108 found in the GLCD example. The pin out on the Display ended up being different, but worked just fine.

My plans are to use the I2C output on the GEN7 Prusa electronics to send the temperature data to the Teensy over the i2c bus. For prototyping, I used the “Bus Pirate” to send i2c commands to the teensy to simulate the GEN7 electronics.
